Prevention measures for wear or damage of conveyor belts


Conveyor belt is common in our daily life, in the transport of goods is commonly used, but in a period of time after the conveyor belt is the phenomenon of wear and tear, so when we need to prevent the transmission belt wear or damage to the measures, we will come together to talk about:
1 to design and manufacture the anti deviation roller device
Conveyor belt deviation is caused by conveyor belt side brush main reason. Therefore, on the basis of the original rack every 10 frame clamping two anti deviation device, the deviation of the conveying belt automatically corrected. This method is simple and easy to operate, deviation preventing effect is very good.
2 transformation of the original shape of the roller
Now the use of the roller are all the end face and the surface of the roller surface into a right angle, the sharp right angle edge in the roller rotation is not flexible, because the conveyor belt carrying goods, conveyor belt to withstand the downward bending force, the edge of the roller conveyor belt conveyor belt longitudinal tear. In order to solve this problem fundamentally, a circular arc shape supporting roller is designed, which replaces the traditional process, even if the conveyor belt load is larger, the conveyor belt is formed between the two series of rollers, and it will not damage the conveyer belt.
The technology involves a kind of high temperature resistant conveyor belt, steel wire rope core it is suitable for conveying material temperature above 250 ℃ high temperature material. No can conveying material temperature over 250 ℃ high temperature resistant conveyor belt, steel wire rope core users can only use heat-resistant steel cord conveyor belt force substitution, heat-resistant steel cord conveyor belt of zonal strength provided by the rubber’s own strength, rubber under the environment of high temperature for a long time use will easy to aging, rubber strength thus fell sharply, less intensity of conveyor belt of zonal until disappear, heat-resistant steel cord conveyor belt can appear the failure phenomena such as longitudinal cracks. This technology provides a skeleton containing transverse reinforcing fiber rope core is high temperature resistant conveyor belt, in the steel cable high temperature resistant conveyor belt laid a kind of high temperature resistant aramid fiber such as polyester, cotton, canvas, canvas in the high temperature environment for long-term use is not easy to aging, high temperature resistant conveyor belt of zonal steel wire rope core strength decline in smaller, slower, steel cable high temperature resistant conveyor belt won’t appear longitudinal crack failure phenomena, such as the design greatly improve the service life of steel cable high temperature resistant conveyor belt.
